Tempod 200X
USB PDF Temperature Data Logger with External Probe
PDF Report Embedded with Extractable Raw Data
Automatically generates encrypted PDF format report, no software required to access data file. PDF report includes recording summaries, statistics, alarm information, graph and optional tabular data. Embedded standard format raw data allows further data processing via TempSen Cloud and 3rd party system.
Software-free Configuration
Rapid programming data logger using configuration file created online, no need to install software or driver for device configuration, multiple platforms compatible.
Air Freight Compliance
Complies with IATA PI970 II and RTCA/DO-160G Environmental Conditions and Test Procedures for Airborne Equipment, qualified for air shipment in active status.
Multiple Alarm Zones
Allows setting multiple alarm zones for different conditions, ensuring comprehensive monitoring and timely alerts.
Password Protection
Device password protection prevents unauthorized manipulation to data logger.
Air Freight Compliance
Complies with IATA PI970 II and RTCA/DO-160G Environmental Conditions and Test Procedures for Airborne Equipment, qualified for air shipment in active status.
- Software-free cold chain monitoring solution, no software is needed for programming and downloading logger
- External sensor probe with extreme low temperature resistance cable allows measurement of extreme low temperature environment
- Repeat start allows restarting new recording without reprogramming
- LCD presents all key information including recording statistics, alarm and running status, remaining battery volume
- Factory 3-point calibration, each logger comes with a NIST traceable calibration certificate
Specifications
| Usage | Multiple Use |
| Sensor | External RTD Sensor Probe (1m) |
| Memory | 28800 readings |
| Measurement Range | -200°C...70°C |
| Accuracy | ±0.5°C (-100°C…70°C), ±1.5°C (other range) |
| Resolution | 0.1°C/°F |
| Start Mode | Manual Start / Auto Start / Temperature Condition |
| Logging Interval | 1 minute to 2 hours |
| Battery | 3.0V lithium battery (replaceable) |
| Battery Life | 18 months |
| Buttons | Start / Stop / View / Mark |
| Display | LCD -OK(√), Alarm(x), alarm zones -Running status -Temperature statistics (max, min, avg) -Remaining battery level -Mark history |
| Auto Data File | Encrypted PDF report with embedded raw data |
| Communication | USB 2.0 |
| Software | TempSen Express Desktop Software |
| System Requirements | Windows 10 / 11 (64-bit) |
| Calibration | Factory 3-point calibration (NIST traceable) |
| Certifications | CE, FCC, RTCA-DO160G, IATA PI970 II, RoHS, WEEE |
| Protection Class | IP65 |
| Dimensions | 100mm L x 40mm W x 12mm H |
| Weight | Approx. 68g |
